FX Maverick leak out of bottle adapter?
- By HogKiller
- PCP Airguns
- 6 Replies
The FX drawings were wrong last I looked, they may have changed them, not sure. I got an updated list and even it was wrong, had a HUGE o-ring in there, but it had the revised o-rings listed.What I had for my Dreamline wasn't all that I needed for this. I just ordered more from Oringsandmore.com based on the NBR 70 or 90 that FX listed for it.
I've been digging deeper into the FX Mavericks o-rings and I've found that there are serious errors in both the online schematic AND the schematic they send with o-ring orders.
The schematic sent has different hardness's i.e. NBR90 instead of NBR70, this makes sense except one is several mm thicker than possible in it's location. The on-line schematic has the old durometer numbers but the right sizes. Numbers below correspond to the online schematic.
13) 10.0 x 1.5 NBR90 inside Regulator hole at bottom of threads
18) 7.5 x 2 NBR70 Regulator Body
20) 4.0 x 1.5 NBR90 End of Piston
23) 4.0 x 1.5 NBR90 Inside Regulator Body
25) 2.0 x 1.0 NBR90 (2x) Adjustment Screw, suggestion heat in boiling water slip on first one, then second one, or if you have a witches hat it’s easier. And no, heating them doesn't mess them up, they return to shape. I lube with Mobile One, the light stuff. No, no explosions or fire coming out of the muzzle.....rats.
