What The FX Pocket Chrono Should Have Been - Rechargable

Jump to latest Follow Reply
douger said:
real barrels now? i got few guns they all got barrels
Click to expand...
Yeah normal gun barrels with enough material to support their own weight, not some thin tubing that requires a bunch of orings in a barrel housing or layers of carbon fiber tubing over it to stop the droop or regular POI shift. You remember when FX gave you a new .22 impact for free and you sold it almost immediately because in your words "it's not my thing." Well the fx barrels aren't my thing. I do like the rest of the gun though.

Upvote 0
heavy-impact said:
I hate buying disposable batteries and I've heard the FX pocket chronograph really eats the AAA money wasters so I modernized it.

I desoldered and removed the 6 battery connectors from the main pcb and removed the plastic battery tray portion from the case and battery compartment cover with a rotary tool. Insulated the back of the pcb with a foam sheet and wired in a 124050 3200mah Li-Po battery pack with integrated bms and added a charge port.

Capacity for three AAA Duracell batteries in series is 970mah vs 3200mah for the Li-Po pack so I'll have about triple the run time now and be able to recharge at least 1000 times.

The battery cost me $8.70 delivered from virusland. FX could've had them built this way for about $2 more per unit. FX stopped including the tripod base also so I had to 3D print one.

Link to battery pack. Link to 3d printable bipod base file

View attachment 206609View attachment 206620
Click to expand...
Great Idea.

Upvote 0
heavy-impact said:
I hate buying disposable batteries and I've heard the FX pocket chronograph really eats the AAA money wasters so I modernized it.

I desoldered and removed the 6 battery connectors from the main pcb and removed the plastic battery tray portion from the case and battery compartment cover with a rotary tool. Insulated the back of the pcb with a foam sheet and wired in a 124050 3200mah Li-Po battery pack with integrated bms and added a charge port.

Capacity for three AAA Duracell batteries in series is 970mah vs 3200mah for the Li-Po pack so I'll have about triple the run time now and be able to recharge at least 1000 times.

The battery cost me $8.70 delivered from virusland. FX could've had them built this way for about $2 more per unit. FX stopped including the tripod base also so I had to 3D print one.

Link to battery pack.
5.5x2.1mm charge port
Charger / AC adapter
Link to 3d printable bipod base file

View attachment 206609View attachment 206620

View attachment 286616
View attachment 286617
Click to expand...
You did an amazing job with this! Did you just drill a hole in the side and insert the charging port? It’s hard to see in your pictures.

Upvote 0
BOOMBBQ said:
You did an amazing job with this! Did you just drill a hole in the side and insert the charging port? It’s hard to see in your pictures.
Click to expand...
Yes and this is the only good spot for it. I wanted to do USB-c but it would've been more complicated due to the footprint of available ports at the time so I kept it simple. When it comes to tools I'm a firm believer in form follows function.

  • Like
Reactions: BOOMBBQ
Upvote 0
1shooter said:
I prefer replaceable rather than built in as batteries can go bad and tool less is best
Like to see common batteries like aa,aaa as I have those around. I use Rechargable eneloops and try not to use the chrony too long as its for testing and confirming but I prefer shooting…
Click to expand...
If a built in battery goes bad you change it just like the expensive throw away batteries that definitely go bad after a few hours. This li-po pack isn't built in though. I could literally swap this battery in two minutes but I'll never have to since it's good for thousands of cycles each lasting 4x longer than the best throw away batteries.
I guess there are some who prefer to ride a horse since cars can go bad.

Upvote 0
+1 on replaceable batteries, just should be batteries that make sense, why the pocket chrono do not have a 18650 battery i will never know.
There are also more square solutions for various cameras,,,,, without it have to be a raw 1 or 2 cell lipo pack in the nude.

I must admit though these batteries like seen in Gopro cameras or my own Osmo action camera + way more action / palm /dslr cameras, well never impressed me.
I would gladly take a slightly larger and heavier action camera to get a replaceable 18650 battery with 3-3500 MAH VS the 2000 or so batteries you get in them today.
Also i would feel more at ease with a round screw in with a coin lid VS the hatch on some "waterproof " cameras today.

Upvote 0
Nice hack!

If I had a new FX Chrono and didn't want to chop it up until the warranty was over, I would just use AAA Lithium rechargeables. I use rechargeable AA AAA and AAA NMH and Lithium batteries in all my stuff that requires those sizes. A good rechargeable AAA or AA will last several years. The charger I use will recharge NMH, NiCad, Lithium and also standard alkaline batteries. Once my remaining rechargeable NMH batteries are toast I will stick with just Lithium.

Upvote 0
My FX chrono is of the first batch shipped here in the US and it took me a year to realized that after about half battery life the chrono was becoming erratic and inconsistent, until I put new alkaline in. Lasted about two weeks with my test work. I started using rechargeable lithium's and get 4 times the use between charges. Inconsistent and eratic went away as well. The linier power delivery of the lithium is a key reason. Paid for themselves many times over.

Patrick

  • Like
Reactions: heavy-impact
Upvote 0
