I have a .22 and looking for sizes of #18, #22 and #25 external barrel o rings. I have extra breech / probe o rings so I don’t need those. I tried the search function but could find anything.
TIA.
TIA.
Need Redwolf o-ring sizes for barrel please
- Thread starter igolfat8
- Start date
Breech is 5 x 1.5 mm. Barrel is 10 x 1.5mm for Standard and 12 x 1.5mm for the HP.
For other calibers for those looking at this thread.... 177 is 4 x 1.5mm, 25 is 6 x 1.5mm. Can't remember the 30 offhand but will look and edit this in a bit.
Bob
For other calibers for those looking at this thread.... 177 is 4 x 1.5mm, 25 is 6 x 1.5mm. Can't remember the 30 offhand but will look and edit this in a bit.
Bob
Upvote 0
Thanks for the quick reply Bob. Mine is a HP .22. Do you know the two sizes for the shroud and air stripper?
70 or 90 Durometer? Buna?
70 or 90 Durometer? Buna?
Upvote 0
I don't .. offhand, but there was a thread at some point that listed them all. All those are 70 D Buna from the factory but I use 75 D Viton as it's much tougher, more chemical resistant and longer lifespan. The only 90 D will be the high pressure ones.
Bob
Bob
Upvote 0
OK Thanks Bob. FYI, I removed mine and measured them as close as I could.
#18 Barrel = 1x12
#22 Shroud = 1.6 x 17
#25 = Stripper 2.5 x 16
Order was placed to O rings and more. I will update this thread after I compare what I ordered (above) to what is actually on my barrel.
#18 Barrel = 1x12
#22 Shroud = 1.6 x 17
#25 = Stripper 2.5 x 16
Order was placed to O rings and more. I will update this thread after I compare what I ordered (above) to what is actually on my barrel.
Upvote 0
Since I suspect the postage is more than the price of the orings, you may want to add the index pin oring too. I think that could be all the orings that come after the release of air and reduction of power. However, it wont address a leak of your stored air.
I believe the oring size is wrong in the part list. I have whjat I believe is the correct size but I'm not at home right now to send to you
I believe the oring size is wrong in the part list. I have whjat I believe is the correct size but I'm not at home right now to send to you
Upvote 0
Yes it is a BRAND NEW GUN that I have YET to shoot! I pulled the barrel and shroud for cleaning and after I did three of the O-rings were chewed up, from just pulling it. Someone else PM'd me saying his did the same thing when he pulled his barrel. He said his must have a burr on the receiver's transfer port. I haven't investigated further on mine yet.
The strange thing is that the inside of my shroud, at the air stripper end, is FILTHY with lead dust accumulation like several tins of pellets have been through it. Yet there was only a 5 shot group from AOA on the test target print out??? Why would there be that must lead dust crud in a brand new gun?
The strange thing is that the inside of my shroud, at the air stripper end, is FILTHY with lead dust accumulation like several tins of pellets have been through it. Yet there was only a 5 shot group from AOA on the test target print out??? Why would there be that must lead dust crud in a brand new gun?
Upvote 0
I've heard of burrs on the TP in the barrel, but I guess it could occur in the receiver too. Those outer O rings are fragile, but I've pulled my barrel many times and haven't replaced one yet. Lightly lube and pull straight and gentle.
The air stripper gets dirty quick, but yours was probably shot more than just one group, shouldn't be a problem. They may shoot 4 or 5 groups before getting one that will look good to the buyer.
The air stripper gets dirty quick, but yours was probably shot more than just one group, shouldn't be a problem. They may shoot 4 or 5 groups before getting one that will look good to the buyer.
Upvote 0
Hi Bob,
Just an update, I received my order today from Oringsandmore.com and discovered I had ordered the 12 x 1.5 O-rings for the barrel. Unfortunately, the cross section of the 1.5 is too thick for the barrel where it inserts into the receiver so I placed another order today for a 1 x 12. I’ll post another update when after I receive those o rings.
