I just tried this impact regulator piston removal too from 910 airgun tuning and repairsl but can't seem to get it to grip onto the piston. I watched the short video more than I care to admit and nothing I do seems to work. Has anyone else run into this issue and have some tips? Thank you
Impact m3 reg piston removal tool
- Thread starter Stewy1412
- Start date
Clean all lubes as best you can that’s on the piston stem, and inside of the tool.
It’s probably over lubed, in combination with the pistons o ring at the base swelled up. Another cause for the difficulty in pulling that piston out is the washers caught up on the inner o ring that’s in the groove under the threads that the reg body threads into. Plan on changing that out.
If your piston is of the original plastic body, just bite the bullet and use long needle nose pliers to yank it out. Meanwhile, order the new brass piston from FXUSA to replace that plastic one
It’s probably over lubed, in combination with the pistons o ring at the base swelled up. Another cause for the difficulty in pulling that piston out is the washers caught up on the inner o ring that’s in the groove under the threads that the reg body threads into. Plan on changing that out.
If your piston is of the original plastic body, just bite the bullet and use long needle nose pliers to yank it out. Meanwhile, order the new brass piston from FXUSA to replace that plastic one
Upvote 0
There isn't really a good way to clean the surfaces and I can't seem to get the washers to fall out which definitely makes me think it is over lubed and making everything stick. I'm probably going to have to try puffing some air through the rear gauge but not really sure what to attach to the hose in order to fit in the gauge hole
Upvote 0
I used a piece of clear plastic tubing, slightly smaller than the piston. I stretched it with small needle-nose pliers, and slid it over the piston end, then wiggled it out.
Upvote 0
Just insert a tool, apply slight pressure, and rethread your bottle slowly. Once air hits the reg port, it’s gonna want to shove the piston and washers out so stay steady on the tool so you don’t have parts flying out.
Of course, quickly unthread the bottle once you’ve accomplished getting the piston out
Of course, quickly unthread the bottle once you’ve accomplished getting the piston out
Upvote 0
