BRK Pathfinder XR - Ready for action!

Jump to latest Follow Reply


I’ll start a thread once ive had some range/hunting time with it 👍

  • Like
Reactions: bbbrownbommer, Jnine and Dairyboy
Upvote 0
@bigmike, here you go… from the out the box tune. It does 25 FPE with the JSB Exact Jumbo 18.13s. You could probably get it to 30 FPE, at the expense of shot count and harmonics.

CPHPs / TP High

Hi: 846 Low: 835 Avg: 841Std: 3 ES: 11 FPE: 22.4


CPHPs / TP Med

Hi: 836 Low: 829 Avg: 834Std: 2.27 ES: 7 FPE: 22


CPHPs / TP Low

Hi: 794. Low: 784 Avg: 789Std: 3.36 ES: 10 FPE: 19.7


JSB Exact Jumbo 18s/ TP High

Hi: 794 Low: 782 Avg: 788Std: 4.94 ES: 12 FPE: 24.8

Upvote 0
Upvote 0
Daystate said:
Hi Airgun Nationers!

The BRK Pathfinder is now being shipped on ever increasing numbers so i though it a good time to share the press release and data on this very compact new rifle. For those of you who have missed it, the BRK/Brocock Pathfinder takes the idea of the super compact Atomic and Ranger but adds a 300cc carbon bottle instead of the 50cc air tube on the Ranger. We have done this using the well established Commander, and adding the ranger barrel and tuning up the Hume-Air regulator from the magnum version. The combination is a small compact and fully equipped carbine that is heavier than the Ranger, but more powerful and with a greater shot count. Tony

BRK PATHFINDER

READY FOR ACTION

View attachment 357620View attachment 357621​


The BRK Pathfinder XR joins the super-light and compact Ranger XR which quickly became a firm favourite with hunters and pest controllers. Building on its success and reputation, the new Pathfinder XR features a lightweight 300cc carbon Kevlar bottle for increased shot count compared to the Ranger XR. Export and FAC models also benefit from higher power output as well. The Pathfinder XR measures a carbine length 22.5 inches with its folding stock deployed, and just 18.5 inches with it retracted, resulting in a rifle that is incredibly fast onto the target and useful in tight situations. It weighs just 6.4lbs, and yet in low power can deliver over 200 shots. .25 calibre models produce energy up to 30 ft/lbs. Super compact and able to be easily transported in a backpack, or optional purpose-built rifle slip. The Pathfinder XR offers superb accuracy at hunting ranges out to 45 yards and beyond and its slick sidelever action enables fast reloading. The Pathfinder features an advanced Huma-Air regulator and newly introduced hammer design. This new system is our most consistent, yet which results in superb performance and accuracy.



PATHFINDER XR​
Length Folded18.5ins
Overall Length25.5ins
Barrel Length10.1ins
Bottle Capacity300cc
Weight (Unscoped)6.4lbs
Available Calibres.177 (4.5mm), .22 (5.5mm) .25 (6.35mm)
CockingSide lever action
Single shot + Magazine13 shot (.177), 11 shot (.22), 10 shot (.25)
Power / .25Up to 30 ft/lb
Power / .22Up to 27 ft/lb*
Power/ .177Up to 18 ft/lb*
Trigger2 stage adjustable for pull weight, length of stage and blade position.
SafetyManual, resettable lever
StockPolyester
OptionsSide Picatinny, 0dB Silencer, AimGrip Bipod
​
Click to expand...
I sure do like that "little-dude" (y)

ThomasT

  • Like
Reactions: Solo1
