Hello AGN:
I sold some of these FX Impact o-ring reseal kits awhile back and they were pretty popular but they didn't include the M3 so I just spent way more time than I care to admit very carefully reviewing the following FX schematics to update the kits to include every o-ring you'll ever likely need to service your beloved Impact:
Each one of these kits will now allow you to fully reseal every o-ring in the action, power plenum, factory regulator(s), barrels and, yes, even the air bottle at least once (with some o-rings to spare) FOR EVERY FX IMPACT MODEL FROM THE MKI (after serial #183534), IMPACT X, MKII (with or without Power Plenum) AND M3 IN 0.22, 0.25 AND 0.30 CALIBERS!!! Please note that most other o-ring kits are model/caliber specific or are only for a specific part of the rifle (action, regulator or barrel) - whereas my kit will include all the o-rings you'll need to reseal the entire rifle (except for some of the older shrouds - but those don't really ever need to be replaced). Here's what's included in each kit (o-rings will be separated by sizes into ziploc bags and properly labeled):
[(quantity) / size / hardness rating / FX schematic part # (MkI / MkII / M3)]
For action: (2) 13.95x2.62mm Buna 70 (M3 action B12)
(4) 9×1.5mm
Buna 70 (action A18/B24 / M3 C49)
(4) 2.2x1mm Buna 70 (action A25/M3 action D94 / M3 power plenum E105)
(4) 3.63×2.62mm X-rings (action A27/B34 / M3 D58/F127 – goes under the air gauges)
(4) 7.66x1.78mm Buna 70 (action A29.1 / M3 D78)
(4) 10x1mm Buna 90 (action A30 / M3 D77.1)
(4) 2.9×1.78mm Buna 90 (action A31/C3 / M3 D77.2)
(4) 6x1mm Buna 90 (action B22.1)
(4) 10x2mm Buna 70 (M3 action D89 #19703)
(4) 9x1.5mm
Buna 90 (power plenum B22)
(2) 20.24x2.62 Buna 70 (power plenum B23)
(4) 5.5x1.5mm Buna 70 (power plenum B25.1 / M3 E104)
(4) 2.84x2.62 Buna 90 (power plenum B23/B25.2 / M3 E103)
(4) 10.5x2mm Buna 70 (power plenum B29 / M3 E109)
(4) 14×1.5mm Buna 70 (action A6/B29.1 / M3 B13)
(4) 2.5x1.5mm Buna 70 (M3 D92)
(2) 14x2mm Buna 70 (M3 D96)
(4) 9x1.5mm Buna 90 (M3 E100)
(2) 25x2.5mm Buna 70 (M3 power plenum E102)
For regulator(s): (4) 4×1.5mm Buna 70 (action C33/C35 / M3 X2-5/X2-7)
(4) 2x1mm Buna 90 (action C38 / M3 X2-1)
(4) 10×1.5mm Buna 90 (action C39 – for serial #’s after 183534 / M3 X2-8)
(4) 7.5x2mm Buna 70 (action C41 – for serial #’s after 183534 / M3 X2-4)
For air bottle: (2) 9.3x2.4mm Buna 90 (bottle 1 / M3 action D89 #5105)
(2) 18x2mm Buna 70 (bottle 5)
(2) 4.5x1.5mm Buna 70 (bottle 7)
For barrel/shroud: 0.22 caliber:
(4) 5.5×1.5mm Buna 70 (barrel 1 – 0.22 caliber breech)
(4) 5.23×2.62mm Buna 70 (barrel 9 - 0.22 liner outside o-rings)
(4) 8x1mm Buna 70 (barrel 6 & 11 - 0.22 liner lock & barrel attachment o-rings)
(4) 10x2mm Buna 70 (barrel 3 & 4 - 0.22 barrel attachment & inlet outer o-rings)
0.25 caliber:
(4) 6.35×1.27mm Buna 70 (barrel 1 – 0.25 caliber breech)
(4) 5.5x2mm Buna 70 (barrel 9 - 0.25 liner outside o-rings)
(4) 9x1mm Buna 70 (barrel 6 & 11 - 0.25 liner lock & barrel attachment o-rings)
(4) 10x2mm Buna 70 (barrel 3 & 4 - 0.25 barrel attachment & inlet outer o-rings)
0.30 caliber:
(4) 7.5×1.5mm Buna 70 (barrel 1 – 0.30 caliber breech)
(4) 6.35×1.27mm Buna 70 (barrel 9 - 0.30 liner outside o-rings)
(4) 10x1mm Buna 70 (barrel 6 & 11 - 0.30 liner lock & barrel attachment o-rings)
(2) 10x2mm Buna 70 (barrel 3 - 0.30 barrel inlet outer o-ring)
(2) 11×1.5mm Buna 70 (barrel 4 - barrel attachment outer o-ring)
(4) 13.94×2.62mm Buna 70 (shroud A6/B6 - sames M3 action B12)
(2) 25x1mm Buna 70 (shroud A9)
(2) 20.3×2.62mm Buna 70 (shroud A13)
(2) 20×2.5mm Buna 70 (shroud A17)
PRICE: $29.99 shipped (each kit)
