FX Impact - Regulator Belleville Washer specs

[StanAccy]

Does anyone have the specs on the belleville washers for a US FX Impact .25 including the count. In one of his videos, Ernest mentioned that his gun had 11 washers. Mine has 10 and I'm wondering if I should grab another to add to the stack.

N



[Brian10956]

I’m not positive but I thought the washers were only used in pairs.



[AirSupply]

There are 11 usually. It is 'very' easy to lose them when you remove the reg. They sometimes stick to the reg housing as you remove it or blow out when you remove the piston.
Check out this video. It also shows you the order of the washers.



[sonny]

great video looks like 11 washers to me



[AirSupply]

Yes sorry 11 is correct. I've corrected earlier post.
Thanks for that Sonny.
Michael



[13brv3]

"and we can tell if you were in there"

Rusty



[AirSupply]

"13brv3""and we can tell if you were in there"

Rusty
FX Impact Regulator Rebuild.



[Drumsnguns]

Hate to ask this but AOA says the little thin washers go on the reg rod first. Pretty sure mine were on last or closest to the reg adjuster screw. I was stupid and did not photograph first.
Can anyone confirm? Thanks



[Brian10956]

"Drumsnguns"Hate to ask this but AOA says the little thin washers go on the reg rod first. Pretty sure mine were on last or closest to the reg adjuster screw. I was stupid and did not photograph first.
Can anyone confirm? Thanks

Watch the video in the third post above it shows you how to do it.



[Drumsnguns]

Thanks Brian, I decided that I was tired, not thinking clearly, and to knock off and hit the sack....got up early before work, watched the video again and decided.....to heck with how I "thought" I saw it as I removed it, I'm going with AOA's vid. Got 'er together, did a quick leak test and then got out at sun up and did a shoot over the chrony. ES was 11 and SD was 4. That's very promising. I'll tweek up the speed a tad and keep checking for leaks/creep but I'd say success! Big thanks to Ernest for supplying a reg puller tool!
